求大神指导，谢了。。。论文所需 ;2m地连墙开挖第一层深2.5m
model null range x -0.4 0.4 y 0 2 z 0 -2.5
apply sxx=0 grad 0 0 11.1e3 range x 0.3 0.5 y 0 2 z 0 -2.5
apply sxx=0 grad 0 0 11.1e3 range x -0.3 -0.5 y 0 2 z 0 -2.5
apply syy=0 grad 0 0 11.1e3 range x -0.4 0.4 y 1.9 2.1 z 0 -2.5
apply szz=-27.75e3 range x -0.4 0.4 y 0 2 z -2.4 -2.6
set mech ratio=3e-5
plot con xd outline on
solve
save 2m第一层开挖.sav
;2m地连墙开挖第二层深5m
model null range x -0.4 0.4 y 0 2 z -2.5 -7.5
apply sxx=27.75e3 grad 0 0 11.1e3 range x 0.3 0.5 y 0 2 z -2.5 -7.5
apply sxx=27.75e3 grad 0 0 11.1e3 range x -0.3 -0.5 y 0 2 z -2.5 -7.5
apply syy=27.75e3 grad 0 0 11.1e3 range x -0.4 0.4 y 1.9 2.1 z -2.5 -7.5
apply szz=-83.25e3 range x -0.4 0.4 y 0 2 z -7.4 -7.6
set mech ratio=3e-5
plot con xd outline on
solve
save 2m第二层开挖.sav
;2m地连墙开挖第三层深2.5m
model null range x -0.4 0.4 y 0 2 z -7.5 -10
apply sxx=83.25e3 grad 0 0 11.1e3 range x 0.3 0.5 y 0 2 z -7.5 -10
apply sxx=83.25e3 grad 0 0 11.1e3 range x -0.3 -0.5 y 0 2 z -7.5 -10
apply syy=83.25e3 grad 0 0 11.1e3 range x -0.4 0.4 y 1.9 2.1 z -7.5 -10
apply szz=-111e3 range x -0.4 0.4 y 0 2 z -9.9 -10.1
set mech ratio=3e-5
plot con xd outline on
solve
